Product Description
We are one of the leading manufacturers, exporters and suppliers of optimum quality Semi Automatic Flat Screen Printing Machine that is used in printing industry. It is operated with a technique that requires image transference from a plate to a rubber blanket and then again to the printing surface. This printing machine is manufactured using premium grade components under the direction of our team of professionals at our technically sound production unit. Moreover, this Semi Automatic Flat Screen Printing Machine is available with us in different specifications as per the specific requirements of clients.
Semi Automatic Flat Screen Printing Machine Properties:
- Unrivaled print standard sole worked in required to run the machine
- Simple alterations and easy running for motley
- Longer and short press strokes are smoothly obtainable by adjusting the length of the rod
- Changeable speed is acquirable by the tread low manual wheel pace modifier. Printing revolution is as well readily changeable by the timekeeper configuration
- Base switch for running and stooping the machine
- Void reception of paper for appropriate arrangement
- Vacuity break off mechanically
- Vacuum shelve is uprightly fixed backward, forward, right, left, down and up
- Electric automation accounting
- Our product can print on several plain base such as on plastic sheets, metal sheets, papers and so forth
- Aluminum or wooden frames are essential
Semi Automatic Flat Screen Printing Machine Technical specifications:
| Model | Minopet L-600 | L-800 |
| Maximum print area | Inches 15"x 22" (381 x 559 mm) | Inches 18" x 24" (456 x 610 mm) |
| Vacuum Table Format | Inches 25 1/2" x 25 1/2" ( 648 x 648 mm) | Inches 27 1/2" x 27 1/2" (698 x 698 mm) |
| Maximum Frame Size | Inches 24" x 30" (610 x 762 mm) | Inches 30" x 30" (762 x 762 mm) |
| Impression Per Hour | 960 to 1200 | 962 to 1200 |
| H.P Machine | 1 H.P | 1 H.P |
| H.P Vacuum | 0.5 H.P | 0.5 H.P |
| Power Required | 220-250V Single phase | 220-250V Single phase |
| | 440 V Three phase | 440 V Three phase |
| Maximum machine Size | H-47" or 1194 mm | H-47" or 1194 mm |
| | L-55" or 1397 mm | L-55" or 1397 mm |
| | B-26" or 659 mm | B-26" or 659 mm |
| Weight | Approx 300-325 Kgs | Approx 300-325 Kgs. |
Dimensions Can be Changed Without any Prior Notice
Enhanced Printing EfficiencyThe semi-automatic flat screen printing machine is purpose-built for consistent, high-quality prints. Its bi-directional print direction and user-friendly interface streamlines the printing process, reducing downtime and improving overall productivity. The sturdy iron construction ensures long-term durability, making it a reliable choice for industrial environments.
Smart PLC-Controlled OperationWith an advanced PLC control system, operators enjoy accurate control over the printing process. Computerized settings allow for swift job setup and repeatable results, enhancing workflow efficiency. This technology minimizes manual errors and ensures each print meets stringent quality standards.
Versatile Power OptionsThe machine supports both 220-250V single-phase and 440V three-phase voltage, making it adaptable for diverse industrial settings. Its flexible power options enable integration into various factory infrastructures without the need for extensive modifications.
FAQ's of Semi Automatic Flat Screen Printing Machine:
Q: How does the semi-automatic flat screen printing machine operate?
A: The machine operates with a PLC control system and computerized interface, allowing for precise control over print settings. Operators load screens and materials, configure required options, and initiate the process, while the machine ensures even, bi-directional printing.
Q: What materials and plate sizes can be used with this machine?
A: This screen printing machine is designed for use with iron plates and accommodates printing surfaces up to 15" x 22" (381 x 559 mm), making it suitable for a wide variety of flat materials used in industrial applications.
Q: When is it advantageous to use a semi-automatic screen printing machine over manual models?
A: A semi-automatic model is ideal when consistent print quality, higher production speeds, and reduced manual labor are desired, offering a balance between manual flexibility and automatic efficiency for small or medium-scale operations.
Q: Where is this machine typically used?
A: Commonly employed in industrial settings such as manufacturing units, export houses, and supplier facilities across India, this machine is engineered for environments requiring reliable, repeated screen printing tasks.
Q: What is the process for setting up and operating the printing machine?
A: Installation involves connecting to a suitable power source (either 220-250V single-phase or 440V three-phase) and securing the machine on-site. Operators then select parameters via the PLC control, load the appropriate screen and substrate, and initiate printing.
Q: How does the bi-directional print direction benefit the production process?
A: Bi-directional printing ensures coverage in both directions, reducing turnaround time and increasing throughput without sacrificing print accuracy or quality.
Q: What are the core benefits of using this semi-automatic screen printing machine?
A: Key benefits include enhanced operational efficiency, precise print quality, reduced labor intervention, robust iron construction for longevity, and flexibility in power requirements to suit various industrial facilities.
